| Task |
Every Week
|
Every 1~3
months
|
Every 6
months
|
Every
year
|
As
neede
|
°ßÀû
½Åû
|
樨毢
|
|
Change the carrier gas trap and purifier
|
|
|
O
|
|
|
|
|
|
ReNEWable Gas Purifier System- New S
|
G3440-60004
|
|
|
|
|
|
|
|
Trap, O2/H2O, 1/8"
|
OT3-2
|
|
|
|
|
|
|
|
Change the split vent trap
|
|
O
|
|
|
|
|
|
|
Split vent trap kit
|
G1544-60610
|
|
|
|
|
|
|
|
Change syringes or syringe needles
|
|
O
|
|
|
|
|
|
|
Syringe, 10ul straight, FN, 26s/42/HP(Autosampler Syringe)
|
9301-0714
|
|
|
|
|
|
|
|
Syringe, 10.0 uL, FN, bevel tip(Manual Syringe)
|
5190-1483
|
|
|
|
|
|
|
|
Change injection port liners
|
O
|
|
|
|
|
|
|
|
Liner,split,straight,glasswool,non-deact
|
19251-60540
|
|
|
|
|
|
|
|
Liner,splitls,sngl-taper,no glswl,deact
|
5181-3316
|
|
|
|
|
|
|
|
Liner,splitless,single-taper, glswl
|
5062-3587
|
|
|
|
|
|
|
|
Liner,split,low prs drop,glswl
|
5183-4647
|
|
|
|
|
|
|
|
Change Liner O-rings
|
|
O
|
|
|
|
|
|
|
Liner O-Ring, Non-Stick
|
5188-5365
|
|
|
|
|
|
|
|
Change Inlet septum
|
O
|
|
|
|
|
|
|
|
Non-Stick BTO Inlet Septa 11mm
|
5183-4757
|
|
|
|
|
|
|
|
Non-Stick Adv Green Inlt Septa 11mm
|
5183-4759
|
|
|
|
|
|
|
|
Non-Stick Long Life Inlt Septa 11mm
|
5183-4761
|
|
|
|
|
|
|
|
Change Inlet gold or stainless steel seal
|
|
O
|
|
|
|
|
|
|
Gold Plated Inlet Seal with Washer
|
5188-5367
|
|
|
|
|
|
|
|
Replace column
|
|
|
|
|
|
O
|
|
|
Universal column nut
|
5181-8830
|
|
|
|
|
|
|
|
MS interface column nut
|
05988-20066
|
|
|
|
|
|
|
|
Ferrules
|
|
|
|
|
|
O
|
|
|
Ferrule Graphite, column id 0.1, 0.2, 0.25, 0.32um
|
5080-8853
|
|
|
|
|
|
|
|
Ferrul Vespel/Graphite, column id 0.2, 0.25um
|
5062-3508
|
|
|
|
|
|
|
|
Ferrul Vespel/Graphite, column id 0.32um
|
5062-3506
|
|
|
|
|
|
|
|
Tune the MSD
|
|
|
|
|
|
|
|
|
Filament assembly(EI)
|
G3170-60050
|
|
|
|
|
|
|
|
Filament assembly(CI)
|
G1099-80053
|
|
|
|
|
|
|
|
Electron multipliers and replacement horn
|
05971-80103
|
|
|
|
|
|
|
|
Triple axis detector assembly_5975 series
|
G3170-80105
|
|
|
|
|
|
|
|
Triple axis detector electron multipliers_5975 series
|
G3170-80103
|
|
|
|
|
|
|
|
Check the foreline pump oil level
|
O
|
|
|
|
|
|
|
|
Replace the foreline pump oil
|
|
|
O
|
|
|
|
|
|
Foreline pump oil, Inland 45, 1L
|
6040-0834
|
|
|
|
|
|
|
|
Check the diffusion pump fluid
|
O
|
|
|
|
|
|
|
|
Replace the diffusion pump fluid
|
|
|
|
|
|
O
|
|
|
Diffusion pump fluid, 18.5mL
|
6040-0809
|
|
|
|
|
|
|
|
Check the calibration vial
|
|
|
O
|
|
|
|
|
|
EI Tune/PFTBA sample, certified
|
8500-0656
|
|
|
|
|
|
|
|
CI Tune/PFTBA MS sample Kit
|
05971-60571
|
|
|
|
|
|
|
|
Clean the ion source
|
|
|
|
|
O
|
|
|
|
Ion source cleaning kit
|
5181-8863
|
|
|
|
|
|
|
